Excellent Optical Function with Infinitive Optical System.

·

Innovative Stand structure, Sharp Image Display, Convenient and Special for Viewing Incubating Cell Tissue.

Viewing Head

Trinocular Head Inclined at300, Interpupillary Distance48-75mm

Eyepiece

High-point, Extra Wide Field Eyepiece EW10×/ 22

Objective

LWD Infinite Plan Objective

4×/ 0.1, WD 18mm

10×/ 0.25, WD 10mm

20×/ 0.4, WD 5.1mm

40×/ 0.6, WD 2.6mm

Infinite Plan Phase Objective

PH10×/ 0.25, WD 10 mm

PH20×/ 0.4, WD 5.1mm

PH40×/ 0.65, WD 0.35mm

Nosepiece

Quintuple Nosepiece

Condenser

ELWD Condenser NA 0.3, LWD 72mm (Without Condenser 150mm)

Centering

Centering Telescope (Φ30MM)

Phase Annulus

10×-20×、40× Phase Annulus Plate

10×-20×、40× Phase Annulus Plate

Stage

Plain Stage 160×250mm

Glass Insert

Attachable Mechanical Stage, X-Y Coaxial Control，Moving Rang120×78mm

Auxiliary Stages70×180mm

Terasaki Holder

Φ38mm Petri Dish Holder

Φ54mm Slide Glass Holder

Focusing

Coaxial Coarse and Fine Adjustment, Vertical Objective Movement
Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation

Illumination

Halogen Lamp 6V/ 30W

Filter

Diameter 45mm, Blue、Green and Ground Glass

Photo Attachment

Video Adapter

Video Adapter with C Mount
